SPECIFICATIONS : Rated Input : 15 W (100 V, 70 V line) Rated Impedance : 100 V line: 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W), 3.3 kΩ (3 W) 70 V line: 330 Ω (15 W), 670 Ω (7.5 W), 1 kΩ (5 W), 2 kΩ (2.5 W), 3.3 kΩ (1.5 W) Sensitivity : 96 dB (1 W, 1 m) (500 Hz - 5 kHz, pink noise) Frequency Response : 45 Hz - 20 kHz (peak -20 dB) Speaker Component : 20 cm (8") coaxial cone-type Dimensions for Fixing Hole : Mounting hole : φ250±3 mm φ9.84"±0.12")Ceiling thickness: 5 - 25 mm (0.2" - 0.98") Speaker Mounting Method : Spring clamp Applicable Cable : 600 V vinyl-insulated cable (IV wire or HIV wire) Solid copper wire: φ0.8 - φ1.6 mm (equivalent to AWG 20 - 14) 7-core twisted copper wire: 0.75 - 1.25 m㎡ (equivalent to AWG 18 - 16) Connection :Push-in connector (bridging terminal-2 branch type) Finish : Baffle: Steel plate, white (RAL 9016 equivalent), paint Grille: Surface-treated steel plate net, white : (RAL 9016 equivalent), paint Dimensions : φ280 × 92 (D) mm (φ11.02" × 3.62") Weight : 1.6 kg (3.53 lb) *Harga Sudah Termasuk PPN dan Ongkir.
